Mercury F3.5 Outboard Motor

Mercury F3.5 Outboard – Powerful, lightweight and reliable outboard motor

The Mercury F3.5 is the perfect choice for boat owners who value a lightweight, compact and powerful propulsion system. This 4-stroke outboard offers 2.6 kW (3.5 HP) of power and impresses with its robust construction, easy handling and high reliability.

Advantages of the Mercury F3.5

✅ Lightweight & portability: Weighing just 18 kg, this outboard is one of the lightest in its class and is easy to transport thanks to its large carrying handle.
✅ Easy operation: The steering pin allows for 360° steering, providing full maneuverability in all directions.
✅ Reliable starting: Thanks to the automatic decompression system, starting is made considerably easier.
✅ Shallow water operation: Multiple trim positions enable trouble-free use in shallow waters.
✅ Durability & corrosion protection: Mercury uses the same high-quality corrosion protection methods as on more powerful models.

Technical details

• Power: 2.6 kW / 3.5 HP
• Full-load speed range: 5000 - 6000 rpm
• Idle speed: 1200 rpm (in gear) - 1300 rpm (at idle)
• Cylinders: 1
• Displacement: 85.5 cm³
• Bore: 55 mm
• Stroke: 36 mm
• Recommended spark plug: NGK DCPR6E
• Gearbox oil capacity: 180 ml
• Gear ratio: 2.15:1
• Bore and stroke: 55 x 36 mm
• Gearbox housing options: Standard
• Fuel system: Carburetor
• Fuel tank: 1.1 l integrated + optional auxiliary tank
• Recommended fuel: Unleaded regular gasoline (91 RON – 95 RON)
• Fuel induction system: 2-valve pushrod (floater valve)
• Engine oil capacity: 300 ml
• Recommended oil: NMMA FC-W Four-stroke SAE 10W-30 (or Synthetic SAE 25W-40)
• Transport and storage: Upright or with the tiller handle facing up
• SmartCraft compatible: No
• Starting: Manual start
• Gear shifting: Forward (F) - Neutral (N)
• Steering: Tiller handle
• Generator: No
• Trim positions: 4
• Weight: 18 kg
• Shaft length: Long shaft (L) – 508 mm
• Counter-rotating gearbox: Not available
• Engine protection boat owner warning system: Over-rev
• Cooling system: Water-cooled with thermostat
• Exhaust system: Through the propeller
• Color: Phantom Black

Expert advice & top service at Marina Wassersport

At Marina Wassersport, you receive not only high-quality outboards, but also first-class advice and excellent customer service. Our expert staff will be happy to help you select the right motor for your boat.

Our service promise:
✔ Free pre-delivery inspection (PDI): Every motor is tested in our test tank to ensure full functionality.
✔ Secure delivery: Shipped in the original protective packaging – dry and cleaned.
✔ Engine oil included: A sufficient quantity of high-quality engine oil is included for the initial fill.
✔ Professional support: If you have any questions or service requests, our experienced team is always available to help: info@marinawassersport.de.

Order the Mercury F3.5 now and set sail with complete confidence!
